DISCLAIMER

I bought this as an open box from newegg and it didn't come with an I/O shield so I'm selling it as is. I never used the mobo due to missing I/O shield.

AMD AM5 Socket: Supports AMD Ryzen 7000 Series Processors DDR5 Compatible: 4SMD DIMMs with AMD EXPO & Intel XMP Memory Module Support Sturdy Power Design: Direct 5+2+2 Phases Digital VRM Solution Stable Connectivity: 2PCIe 4.0 x4 M.2, USB 3.2 Gen 1 Type-C Fast Networking: 2.5GbE LAN Fine Tuning Features: Smart Fan 6, Q-Flash Plus Update BIOS without installing, CPU, Memory, and GPU"

Brand GIGABYTE Model B650M D3HP AX Supported CPU CPU Socket Type AM5 CPU Type Ryzen 7000 Series / Ryzen 8000 Series Chipsets Chipset AMD B650 Memory Number of Memory Slots 4x288pin (DDR5) Memory Standard DDR5 5200 Maximum Memory Supported 192GB Channel Supported Dual Channel ECC Supported Non-ECC Buffer Supported Un-buffered Memory Feature Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules Support for AMD EXtended Profiles for Overclocking (AMD EXPO) and Extreme Memory Profile (XMP) memory modules Expansion Slots PCI Express 4.0 x16 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x16 PCI Express x1 1 x PCI Express x1 slot, supporting PCIe 3.0 and running at x1 Storage Devices SATA 6Gb/s 4 x SATA 6Gb/s M.2 Integrated in the CPU:

• 1 x M.2 connector (Socket 3, M key, type 2580 PCIe 4.0 x4/x2 SSD support) (M2A_CPU) Chipset:
• 1 x M.2 connector (Socket 3, M key, type 22110/2280 PCIe 4.0 x4/x2 SSD support) (M2C_SB) SATA RAID RAID 0, RAID 1, and RAID 10 support for SATA storage devices Additional RAID Controller RAID 0, RAID 1, and RAID 10 support for NVMe SSD storage devices Onboard Audio Audio Channels 7.1 Channels Onboard LAN Max LAN Speed 2.5Gbps Wireless LAN Wi-Fi 802.11 ax Bluetooth BLUETOOTH 5.3 Rear Panel Ports Back I/O Ports 1 x PS/2 keyboard/mouse port 1 x USB Type-C port, with USB 3.2 Gen 1 support 3 x USB 3.2 Gen 1 ports 2 x USB 2.0/1.1 ports 1 x HDMI port 2 x DisplayPorts 1 x RJ-45 port 3 x audio jacks Internal I/O Connectors Onboard USB 1 x USB Type-C header, with USB 3.2 Gen 1 support 1 x USB 3.2 Gen 1 header 2 x USB 2.0/1.1 headers Other Connectors 1 x CPU fan header 2 x system fan headers 2 x addressable LED strip headers 1 x RGB LED strip header 2 x M.2 Socket 3 connectors 4 x SATA 6Gb/s connectors 1 x front panel header 1 x front panel audio header 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0/GC-TPM2.0 SPI V2 module only) 1 x Q-Flash Plus button 1 x reset jumper 1 x Clear CMOS jumper Physical Spec Form Factor Micro ATX Dimensions (W x L) 9.6" x 9.6" Power Pin 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector Software Feature Windows 11 Support for Windows 11 64-bit Support for Windows 10 64-bit Features Features Support for GIGABYTE Control Center (GCC)

• Available applications in GCC may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.

Support for Q-Flash Support for Q-Flash Plus Additional Information Date First Available September 04, 2024 View Less expand_less View Less expand_less Inaccurate specs? Let us know Question about the product info? OR Warranty & Returns Return Polici
