Home Assistant Green

Hardware specifications

SoC Rockchip RK3566 SoC with quad-core Arm Cortex-A55 CPU

CPU Frequency 1.8 GHz

Storage 32 GB eMMC flash drive

Memory 4 GB LPDDR4X

Interfaces Status LEDs White (power indicator) Green (activity indicator) Yellow (system health indicator)

Power supply DC barrel connector, 5.5 mm * 2.1 mm 12 V DC, 1 A

Battery CR2032. Not included. Optional.

Energy consumption Idle: ~1.7 W at 12 V Load: ~3 W at 12 V

USB 2x USB 2.0 Type-A Host ports, 5 V up to 2 A (combined)

Display HDMI port, for diagnostic purposes only

External storage MicroSD slot, for recovery purposes only

Networking Gigabit Ethernet port

Dimensions and weight

Length 112 mm / 4.41 inches

Width 112 mm / 4.41 inches

Height 32 mm / 1.26 inches

Weight 340 g / 12 oz

Materials

Enclosure Semi-transparent polycarbonate plastic

Heatsink Anodized aluminum

Packaging Chipboard

Environmental conditions for operation

Temperature 0 °C to 40 °C 32 °F to 104 °F

Humidity Non-condensing

Room conditions Indoor use only Keep in dry, not excessively dusty environment as this can cause damage to the unit.

Product information Model No. NC-GREEN-1175
