General

Model: O11D MINI-S Color: Snow White Case Type: Mini Tower (ATX Mid Tower) Dimensions (D × W × H): 420mm × 269.5mm × 380mm (16.5" × 10.6" × 15.0") Volume: ~43 L

Compatibility

Motherboard: E-ATX (max 280mm wide) / ATX / Micro-ATX / Mini-ITX PSU: SFX / SFX-L (up to ~165mm)

Clearances

GPU Length: up to 395mm GPU Height: up to 159mm CPU Cooler Height: up to 172mm

Materials

Body: 0.8mm SPCC steel Side/Top Panel: 4mm Tempered Glass Top & Left Panel: 2mm Aluminum (white powder coated)

Fan Support (up to 9 total)

Top: 3× 120mm or 2× 140mm Side: 2× 120mm or 2× 140mm Bottom: 3× 120mm or 2× 140mm Rear: 1× 120mm

Radiator Support

Top: 360mm / 280mm / 240mm Side: 280mm / 240mm Bottom: 360mm / 280mm / 240mm

Storage

2× 3.5" HDD or SSD (back plate) 2× 2.5" SSD (right side)

Expansion Slots

3, 5, or 7 slots (modular back panel — user selectable)

Front I/O

2× USB 3.0 (USB 3.2 Gen 1 Type-A) 1× USB 3.1 Type-C (USB 3.2 Gen 2) 1× HD Audio combo jack Power button

Dust Filters

1× Top, 1× Bottom, 2× Side
