🔌 General

Form Factor: ATX

Chipset: AMD X870

CPU Socket: AMD AM5 (Supports Ryzen™ 7000, 8000 & 9000 Series)

💻 Memory

Memory Type: DDR5

Memory Channels: Dual Channel

DIMM Slots: 4 x 288-pin

Max Memory: Up to 256 GB

Supported Memory Speed: DDR5-4800 up to high OC speeds (varies by kit)

📦 Expansion Slots

PCIe x16: 1 × PCIe 5.0 x16

PCIe x1: 2 × PCIe 3.0 x1

💾 Storage

M.2 Slots: 3 × M.2 (1 × PCIe 5.0 x4 + 2 × PCIe 4.0)

SATA: 4 × SATA 6 Gb/s

🌐 Networking

Ethernet: Realtek 2.5GbE LAN

Wi-Fi: Wi-Fi 6 (802.11ax) + Bluetooth (via RTL8851BE)

🔌 Rear I/O Connectivity

USB4 Type-C: 2 × USB4 (up to 40 Gb/s with DP-Alt)

USB 3.2 Gen2: 1 × USB-A

USB 3.2 Gen1: 3 × USB-A

USB 2.0: 4 × USB-A

HDMI: 1 × HDMI (requires CPU with iGPU)

🔊 Audio

Codec: Realtek HD Audio

Channels: 8-Channel Audio with High-Quality Caps

🌟 Features

VRM: Twin Digital 8+2+2 Phase Power Design

Thermal: VRM Armor & M.2 Thermal Guard

EZ-Latch & Screwless M.2 Design

Q-FLASH Plus BIOS Flash Button

RGB Fusion + ARGB Headers (addressable LED + RGB)

Smart Fan 6 with Multiple Fan Headers

Wi-Fi EZ-Plug Antenna Adapter
