General

Wattage: 750 W total output

Form Factor: ATX 3.1 compatible

Efficiency: 80 PLUS Gold (up to ~90%)

Modular: Full modular design for easy cable management

Fan: 120 mm Fluid Dynamic Bearing fan

Protection Features: OCP, OVP, OPP, OTP, SCP, UVP

Power Excursion: Up to 1500 W peak (200% surge for 100 µs)

Input

Voltage: 100‑240 VAC

Frequency: 47–63 Hz

Active PFC: Yes

Output Rails

+5 V @ 20 A

+3.3 V @ 20 A

+12 V @ 62 A (primary rail for CPU/GPU)

-12 V @ 0.3 A

+5 Vsb @ 2.5 A

Total Combined: 750 W

Connectors

ATX 24‑pin: 1

EPS (CPU 8‑pin): 2

PCI‑E 5.0 (16‑pin): 1 native (supports ~450 W for next‑gen GPUs)

PCI‑E (6+2 pin): 3

SATA: 8

Molex (4‑pin): 4

FDD: 1

Physical

Dimensions: ~140 × 150 × 86 mm

Cooling: Single 120 mm fan with fluid dynamic bearings
