🧠 Graphics & Architecture

GPU: NVIDIA GeForce RTX 5080 (Blackwell architecture)

CUDA Cores: 10,752

Tensor Cores: Yes (AI/DLSS support)

RT Cores: Yes (hardware ray tracing)

⏱️ Clocks

Base Clock: ~2295 MHz

Boost Clock: ~2617–2780 MHz (varies by sub-model)

💾 Memory

Memory Size: 16 GB

Memory Type: GDDR7

Memory Interface: 256-bit

Memory Speed: 30 Gbps effective

Memory Bandwidth: ~960 GB/s

🔌 Interface & Outputs

PCI Express: PCIe 5.0 x16

Video Outputs: • 3 × DisplayPort 2.1b • 1 × HDMI 2.1b

Max Resolution: Up to 8K 165 Hz with DSC

⚡ Power & Requirements

TDP (Typical Power Draw): ~360 W

Power Connector: 1 × 16-pin (12VHPWR)

Recommended PSU: ~850 W

🧰 Cooling & Build

Cooling: Triple-fan active cooling solution

Form Factor: Triple-slot card (large heatsink & fans)

Dimensions: ~328.7 × 138 × 71 mm / ~12.94″ × 5.42″ × 2.35″

🖥️ Features

DLSS 4 support for AI-enhanced performance

NVIDIA Reflex 2 for reduced latency

PCIe Gen 5 support

Multi-display support (up to 4)
