🧠 GPU & Architecture

GPU Architecture: AMD RDNA 4 (Navi 44 XT)

Stream Processors: 2,048

Compute Units: 32

Graphics Features: DirectX 12 Ultimate, Vulkan, OpenGL, advanced Ray Tracing & AI-accelerated units

⏱ Clock Speeds

Base Clock: Up to ~1,900 MHz

Game (Typical) Clock: Up to ~2,780 MHz

Boost Clock: Up to ~3,320 MHz

💾 Memory

Memory Size: 16 GB GDDR6

Memory Bus: 128-bit

Memory Clock: ~20 Gbps effective

Memory Bandwidth: ~340 GB/s

🎮 Interface & Power

PCIe Interface: PCIe 5.0 ×16

Power Connector: 1× 8-pin PCIe

Recommended PSU: ~450 W (system)

Board Power (Typical): ~160–182 W range for OC variants (varies by specific model and cooling)

🖥 Display Outputs

DisplayPort: 2× DisplayPort 2.1a/b (depending on version)

HDMI: 1× HDMI 2.1b

🧊 Cooling & Build

Cooling Solution: Dual-fan or Triple-fan design (varies by SKU)

Card Profile: Dual-slot

Typical Length: ~270–290 mm (partner design dependent) — actual length varies by cooler variant.

🛠 Software & Features

AMD Software: Adrenalin Edition (driver suite with tuning tools)

FidelityFX Super Resolution 4 (FSR4) & Radeon Super Resolution support

Smart Access Memory support with compatible Ryzen CPUs

AV1 Encode/Decode + HEVC/H264 support

📊 Summary

The XFX Swift RX 9060 XT 16 GB OC is a modern mid-range GPU aimed at high-refresh 1080p and solid 1440p gaming, with ample VRAM for demanding workloads and future-proofing thanks to RDNA 4 features like hardware ray tracing, AI acceleration, and upscaling technologies. The 16 GB variant particularly stands out for handling heavier textures and larger game assets compared to 8 GB models.
