Biostar B660MXC PRO DDR4 Intel LGA 1700 ATX Motherboard

ASRock Z690 EXTREME LGA 1700 (14th,13th,12th Gen) SATA 6Gb/s DDR4 ATX Intel Motherboard

**Ripjaws S5 DDR5-5600 CL30-36-36-89 1.25V 64GB (2x32GB)**
Compatible with Intel and AMD (check note below)

- Model: F5-5600J3036D32GX2-RS5K

- Memory Type: DDR5
- Capacity: 64GB (32GBx2)
- Multi-Channel Kit: Dual Channel Kit
- Tested Speed (XMP/EXPO): 5600 MT/s
- Tested Latency (XMP/EXPO): 30-36-36-89
- Tested Voltage (XMP/EXPO): 1.25V
- Registered/Unbuffered: Unbuffered
- Error Checking (ECC): Non-ECC
- SPD Speed (Default): 4800 MT/s
- SPD Voltage (Default): 1.10V
- Fan Included: No
- Features: Intel XMP 3.0 (Extreme Memory Profile) Ready

SN: 22332696406 SN: 22332696405


**Note: As best practice, please make sure to UPGRADE the BIOS of your motherboard to the latest version available which will help to minimize potential issues with new RAM modules.**

G.Skill Ripjaws S5 DDR5-5600 CL30-36-36-89 64GB (2x32GB)

**ASUS B650M-A Prime AX II AMD AM5 microATX Motherboard**

SEALED - BRAND NEW

PLEASE LET ME KNOW IF YOU WANT ME TO UPDATE THE BIOS before shipping it!


**Key Features**
- AMD B650
- AMD AM5 Ryzen Processors
- 192GB Dual Channel 4 x 288pin DIMM Support

PRODUCT INFORMATION
- Mfr Part#: PRIMEB650MAAX2
- UPC: 197105020481

GENERAL SPECIFICATIONS
- Packaging: Retail
- Chipset: AMD B650
- BIOS: 256 Mb Flash ROM, UEFI AMI BIOS

CPU SUPPORT
- AMD CPU Support: Ryzen
- Socket Type: AM5

MEMORY SPECIFICATIONS
- ECC:
Non-ECC; Non-Registered
ECC; Non-Registered

- Memory Type:
DDR5-4800
DDR5-5200
DDR5-5000

- Memory Speeds Supported:
7600+(OC)/7200(OC)/7000(OC)/6800(OC)/6600(OC)/6400(OC)/6200(OC)/6000(OC)/5800(OC)/5600(OC)/5400(OC)/5200/5000/4800 MHz

- Memory Slots: 4 x 288pin DIMM
- Memory Channel Support: Dual Channel
- Max Memory Supported: 192GB
- Maximum Memory Supported Per Slot: 48GB
- Supported Memory Technologies
ECC Memory Supported
Non-ECC Memory Supported
Unbuffered Memory Supported

VIDEO SPECIFICATIONS
- Onboard Graphic Chipset: Requires CPU with Integrated Graphics

STORAGE SPECIFICATIONS
- M.2 Port Type:
2242
2260
2280

- SATA Express:
2 x M.2 Socket 3
M Key

- SATA 6Gb/s: 8

- RAID Support:
RAID 0
RAID 1
RAID 10

AUDIO SPECIFICATIONS
- Audio Channels: 7.1

NETWORKING
- WiFi Support: Onboard WiFi
- LAN Chipset: Realtek 2.5Gb Ethernet
- LAN Speed: 10/100/1000/2500Mbps

- Wireless Technology:
802.11b
802.11g
802.11a
WiFi 4 (802.11n)
WiFi 5 (802.11ac)
WiFi 6 (802.11ax)
Bluetooth v5.2

EXPANSION SLOTS
- PCI Express 4.0 x16: 4

BACK PANEL PORTS
- Legacy Ports: 1 x PS/2
- LAN Ports: 1 x 10/100/1000/2500 RJ-45 LAN

- Audio Ports
1 x 3.5 mm Microphone
1 x 3.5 mm Line-In
1 x 3.5 mm Line-Out

- Specialty Ports: 2 x WiFi Antenna Ports

- USB 2.0: 4 x USB 2.0 (Type-A)

- USB 3.1:
2 x USB 3.2 (Gen 1 Type-A)
2 x USB 3.2 (Gen 2 Type-A)

- Video Connectors:
1 x VGA 15-pin
1 x HDMI 2.1
1 x DisplayPort 1.4

INTERNAL I/O & CONNECTORS
- Headers:
3 x System Fan Header
2 x CPU Fan Header

- USB:
2 x USB 2.0 Headers (4 Ports)
1 x USB 3.2 Gen 1 Type-A Header (2 Ports)
1 x USB 3.2 Gen 1 Type-C Header (1 Port)

POWER
- Power Connectors:
1 x 24-pin ATX Connector
1 x 8-pin +12 V Connector

- ATX Connector: 24-pin ATX Power Connector

PHYSICAL SPECIFICATIONS
- Depth: 9.60 in. (243.84 mm)
- Width: 9.60 in. (243.84 mm)

Form Factor: microATX

PACKAGE CONTENTS
- What's in the Box: Motherboard, 2x SATA Cables, Antenna, I/O Shield, M.2 Screws, Manual

ASUS Prime B650M-A AX II for AMD 7000 and 8000 series

**ASRock B760M Pro RS/D4 WiFi Intel LGA 1700 microATX Motherboard**

Mfr Part#: MBB760MPRORSD4W UPC: 4710483941719


**Key Features**
- Intel B760
- Intel LGA 1700 Processors
- 128GB Dual Channel 4 x 288pin DIMM Support

**SPECIFICATIONS:**
- Chipset: Intel B760
- BIOS: 128Mb AMI UEFI Bios
- Intel CPU Support: Core i7, Core i5. Core i3, Celeron, Pentium, Core i9
- Socket Type: LGA 1700
- Non-ECC: Non-Registered
- ECC: Non-Registered
- Memory Type:
DDR4-2133
DDR4-2400
DDR4-2666
DDR4-2933
DDR4-3200
DDR4-2800
DDR4-3000

- Memory Slots: 4 x 288pin DIMM
- Memory Channel Support: Dual Channel
- Max Memory Supported: 128GB
- Maximum Memory Supported Per Slot: 32GB
- Supported Memory Technologies: ECC Memory Supported and Non-ECC Memory Supported
- Onboard Graphic Chipset: Requires CPU with Integrated Graphics
- M.2 Port Type:
2242
2260
2280

- SATA Express:
2 x M.2 Socket 3
M Key
1 x M.2 Socket 3
E Key

- SATA 6Gb/s: 4
- RAID Support:
RAID 0
RAID 1
RAID 5
RAID 10

- Audio Chipset: Realtek ALC897
- Audio Channels: 7.1
- WiFi Support: M.2 Slot
- LAN Chipset: Dragon RTL8125BG
- LAN Speed: 10/100/1000/2500Mbps
- Wireless LAN Chipset: Intel 2x2 Wi-Fi 6E
- Wireless Technology:
802.11b
802.11g
802.11a
WiFi 4 (802.11n)
WiFi 5 (802.11ac)
WiFi 6 (802.11ax)
Bluetooth v5.3

- PCI Express 4.0 x16: 2
- PCI Express x1: 1
- Legacy Ports:: 1 x PS/2
- LAN Ports: 1 x 10/100/1000/2500 RJ-45 LAN
- Audio Ports:
1 x 3.5 mm Microphone
1 x 3.5 mm Line-In
1 x 3.5 mm Line-Out

- Specialty Ports: 2 x WiFi Antenna Ports
- Video Connectors:
1 x HDMI 2.1
1 x DisplayPort 1.4

- USB 3.1:
3 x USB 3.2 (Gen 1 Type-A)
1 x USB 3.2 (Gen 1 Type-C)

- USB 2.0: 2 x USB 2.0 (Type-A)

**INTERNAL I/O & CONNECTORS**
- Headers:
1 x CPU Fan Header
4 x System Fan Header
1 x Water Pump Header

- USB
2 x USB 2.0 Headers (4 Ports):
1 x USB 3.2 Gen 1 Type-A Header (2 Ports)
1 x USB 3.2 Gen 1 Type-C Header (1 Port)

- Power Connectors:
1 x 24-pin ATX Connector
1 x 8-pin +12 V Connector

- ATX Connector: 24-pin ATX Power Connector

**PHYSICAL SPECIFICATIONS**
- Depth: 9.60 in. (243.84 mm)
- Width: 9.60 in. (243.84 mm)
- Form Factor: microATX

ASRock B760M Pro RS/D4 Motherboard for Intel 12th 13th and 14th Generation CPUs (LGA1700)

64GB Crucial (2X32GB) DDR4 3200 MHz CL22 2RX8 260-Pin SO-DIMM Memory Module CT32G4SFD832A

OCCT Certificate:
https://www.ocbase.com/stabilityCertificate/664f51c4ba3bd6ece60d4433


**General tech specs**
- DIMM type: Unbuffered
- Technology: DDR4
- Density per module: 32GB
- Module quantity:	2
- Voltage: 1.2V
- Module type: SODIMM
- Die Density: 16Gb
- Default and performance recovery profiles
- Default(JEDEC): 22-22-22

64GB kit DDR4 3200 MHz CL22 SO-DIMM Memory

**MSI PRO Z690-A DDR5 Motherboard ready for Intel 14th, 13th, 12th Gen in great condition**

- The latest BIOS version installed: 7D25vAH

- Tested with 4 RAM modules of different brands and I was able to enable XMP successfully.

---------
- Mfr Part#: PRO Z690-A
- UPC: 824142270387
- Chipset: Intel Z690

- Intel CPU Support:
Core i7
Core i5
Core i3
Celeron
Pentium
Core i9

- Socket Type: LGA 1700

MEMORY SPECIFICATIONS
- Memory Type: DDR5-4800
- Memory Speeds Supported:
6400(OC)/ 6200(OC)/ 6133(OC)/ 6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5333(OC)/ 5200(OC)/ 5066(OC)/ 5000(OC)/ 4800

- Memory Slots: 4 x 288pin DIMM
- Memory Channel Support: Dual Channel
- Max Memory Supported: 128GB
- Maximum Memory Supported Per Slot: 32GB
- Supported Memory Technologies: Non-ECC Memory Supported

VIDEO SPECIFICATIONS
- Onboard Graphic Chipset: Requires CPU with Integrated Graphics
- Multi-GPU Support: 2-Way CrossFireX

STORAGE SPECIFICATIONS
- M.2 Port Type:
2242
2260
2280
22110

- SATA Express: 4 x M.2 Socket 3 M Key
- SATA 6Gb/s: 6
- RAID Support:
RAID 0
RAID 1
RAID 5
RAID 10

AUDIO SPECIFICATIONS
- Audio Chipset: Realtek ALC897
- Audio Channels: 7.1

NETWORKING
- LAN Chipset: Intel I225-V
- LAN Speed: 10/100/1000/2500Mbps

EXPANSION SLOTS
- PCI Express 5.0 x16: 1
- PCI Express 3.0 x16: 2
- PCI Express x1: 1

BACK PANEL PORTS
- Legacy Ports: 1 x PS/2
- LAN Ports: 1 x 10/100/1000/2500 RJ-45 LAN
- Audio Ports:
1 x 3.5 mm Microphone
1 x 3.5 mm Line-In
1 x 3.5 mm Rear Speaker
1 x 3.5 mm Subwoofer
1 x 3.5 mm Side Speaker
1 x 3.5 mm Line-Out

- USB 2.0: 4 x USB 2.0 (Type-A)
- USB 3.1:
1 x USB 3.2 (Gen 2x2 Type-C)
1 x USB 3.2 (Gen 2 Type-A)
2 x USB 3.2 (Gen 1 Type-A)

- Video Connectors: 1 x HDMI 2.1

INTERNAL I/O & CONNECTORS
- Headers:
1 x CPU Fan Header
1 x Water Pump Header
6 x System Fan Header

-USB:
2 x USB 2.0 Headers (4 Ports)
2 x USB 3.2 Gen 1 Type-A Headers (4 Ports)
1 x USB 3.2 Gen 2 Type-C Header (1 Port)

POWER
- Power Connectors:
1 x 24-pin ATX Connector
2 x 8-pin +12 V Connector

ATX Connector: 24-pin ATX Power Connector

PHYSICAL SPECIFICATIONS
- Depth: 12.00 in. (305.00 mm)
- Width: 9.61 in. (244.00 mm)
- Form Factor: ATX

MSI PRO Z690-A DDR5 Motherboard ready for Intel 14th, 13th, 12th Gen

Achieve studio-like illumination and always be perfectly lit with the Razer Kiyo—an all-in-one Full HD webcam featuring a powerful, multi-step ring light. Backed by a fast, accurate autofocus and fully customizable settings, it’s your time to shine in professional streaming.

- FULL HD RESOLUTION — Experience crisp, detailed video and audio recording in 720p 60 FPS / 1080p 30 FPS. Works great for streaming, gaming, recording, video calling, conferencing, and online school. Audio Codec: 16 bit 48 KHz

- CONVENIENT, BUILT-IN LIGHTING — Features a 5600K daylight-balanced ring light around the camera that provides even lighting without the hassle of additional lighting equipment

- ADJUSTABLE BRIGHTNESS — Make quick adjustments to the brightness level by simply rotating the built-in ring light. There's no need to configure software settings

- SUPERIOR LOW-LIGHT PERFORMANCE — Reduces graininess and brings out details to show the best light even in darker environments

- COMPACT, FOLDING DESIGN — Sleek look for any gaming setup or office, and perfect for on-the-go content creators

- COMPATIBILITY — Streamlabs certified and works with popular platforms like OBS, XSplit, Twitch, YouTube, Zoom, Microsoft Teams, and Skype

Model:RZ19-02320100-R3U1

Razer - Kiyo 1920 x 1080 Webcam with Adjustable Ring Light - Black

CPU Contact Frame Anti-Bending Buckle for Intel 12th 13th and 14th Gen LGA1700 Bracket Traceless Installation (Black)

-【Supported Specifications】Intel 12th, 13th, and 14th Gen LGA 1700 CPUs, chipset is H610,B660,Z690 series.

-【Well-Made】The CPU anti-bending buckle is made of aluminum alloy anodized process and has a precise structure that does not damage the CPU.

-【Anti-Bending】Prevents the CPU processors from bending. The heat sink can be fully installed on the CPU processor's cover, improving the heat dissipation efficiency, stability, and performance of the CPU.

-【Traceless Installation】The anti-bending buckle has a insulated footpad on the reverse side to prevent the CPU cover from being worn and the motherboard from being damaged.

-【What You Get】1 x LGA 1700 bracket, 1 x L-shaped screwdriver, 1 x TF7 2g (12.8 w/m.k).

CPU Contact Frame for Intel 12th 13th and 14th Gen LGA 1700

ASRock Z690 EXTREME LGA 1700 (14th,13th,12th Gen) Intel Z690 SATA 6Gb/s DDR4 ATX Intel Motherboard


-UPC: 4710483936067
- MODEL: MBZ690EXTREME
- Brand: ASRock
- CPU Socket: LGA 1700
- 13 Phase SPS Dr.MOS Power Design
- RAM Memory Technology: DDR4
- Supports DDR4 5000MHz (OC)
- 1 PCIe 5.0 x16, 1 PCIe 4.0 x16, 1 PCIe 3.0 x16, 1 PCIe 3.0 x1
- Graphics Output Options: HDMI, DisplayPort
- Realtek ALC1220 7.1 CH HD Audio Codec, Nahimic Audio
- 8 SATA3
- 2 Hyper M.2 (PCIe Gen4 x4)
- 1 Ultra M.2 (PCIe Gen3 x4 & SATA3)
- 1 USB 3.2 Gen2x2 Front Type-C
- 2 USB 3.2 Gen2 (Rear Type A+C)
- 8 USB 3.2 Gen1 (4 Rear, 4 Front)
- Dragon 2.5G LAN, Intel® Gigabit LAN

More details about the specs here:
https://www.asrock.com/mb/Intel/Z690%20Extreme/index.asp#Specification

**PLEASE read, check the pictures showing how the motherboard condition. Updated to latest BIOS version: 17.03 from 2024/01/12**

**Biostar B660MXC PRO DDR4 Intel LGA 1700 ATX Motherboard in great condition**

- The latest BIOS version installed: B66EO912.BSS

- Tested with 4 RAM modules of different brands and I was able to enable XMP successfully. Also installed two M.2 nvme drives to prove that they work. You can also check the YouTube video to see the first time I upgraded the BIOS of the motherboard.

- Originally this did not come with a Wifi module, but in this case comes with a module (AW-CB304NF), but without antennas (usually they will cost you under 20 USD online). Check the official page for more details:
https://www.biostar.com.tw/app/en/mb/introduction.php?S_ID=1072#specification

- Does not include IO shield.

Main features:
- Supports 12th/ 13th/ 14th Generation Intel Core™ Processor
- Intel B660 single-chip architecture
- Supports 4-DIMM DDR4- 1866/ 2133/ 2400/ 2666/ 2800/ 2933/ 3200/ 3600(OC)/ 3733(OC)/ 3800(OC)/ 3866(OC)/ 4600+(OC) up to 128 GB Memory

- Supports PCIe 4.0
- Supports PCIe M.2 4.0 (64Gb/s)
- Supports HDMI 4K2K
- Supports USB 3.2 Gen2

WD_BLACK 250GB SN770 NVMe Internal Gaming SSD Solid State Drive - Gen4 PCIe, M.2 2280, Up to 4,000 MB/s - WDS250G3X0E

- Digital Storage Capacity: 250 GB
- Hard Disk Interface: NVMe
- Connectivity Technology: NVMe
- Brand: WD_BLACK
- Special Feature: WD_BLACK Dashboard
- Hard Disk Form Factor: 2.5 Inches
- Hard Disk Description: Solid State Drive
- Compatible Devices: Laptop, Motherboards
- Installation Type: Solid State Drive
- Color: Black

WD_BLACK 250GB SN770 NVMe Internal Gaming SSD Solid State Drive - Gen4 Up to 4,000 MB/s

ASUS GeForce RTX 3090 24GB TUF GAMING OC GDDR6X Video Graphics Card with original box

MODEL: TUF-RTX3090-O24G-GAMING

Serial Number: M1YVKP006505JVH


The following tests were performed without any OC activated by a switch or configured by software:

**OCCT STABILITY CERTIFICATE**
https://www.ocbase.com/stabilityCertificate/65af00129476a49a5bee0c4c

**TIME SPY**
https://www.3dmark.com/spy/44986140

**PORT ROYAL**
https://www.3dmark.com/pr/2766627

**SPEED WAY**
https://www.3dmark.com/sw/1155567

**Notes**
- BIOS: 94.02.42.00.b4 [UEFI]
- Driver used: 31.0.15.4665 (GeForce 546.65)


**SPECS**
- Bus Standard: PCI Express 4.0
- OpenGL: OpenGL®4.6
- Video Memory: 24GB GDDR6X
- Engine Clock
- OC mode : 1770 MHz (Boost Clock)
- Gaming mode : 1740 MHz (Boost Clock
- CUDA Core: 10496
- Memory Speed: 19.5 Gbps
- Memory Interface: 384-bit
- Resolution: Digital Max Resolution 7680 x 4320
- Interface
Yes x 2 (Native HDMI 2.1)
Yes x 3 (Native DisplayPort 1.4a)
HDCP Support Yes (2.3)

- Dimensions: 11.8 " x 4.99 " x 2.03 " Inch / 29.99 x 12.69 x 5.17 Centimeter
- Power Connectors: 2 x 8-pin
- Slot: 2.7 Slot
- AURA SYNC: ARGB

ASUS GeForce RTX 3090 24GB TUF GAMING OC GDDR6X Video Graphics Card

**B660M-A Pro DDR4 Intel LGA 1700 ATX Motherboard in great condition**

- Mfr Part# PRO B660M-A DDR4
- UPC: 0824142276198

- The latest BIOS version installed: 7D43v1G
- Tested with 4 RAM modules of different brands and I was able to enable XMP successfully.
- Does not include IO shield.

- Chipset: Intel B660

- Intel CPU Support 12th, 13th and 14th Gen
Core i9
Core i7
Core i5
Core i3
Celeron
Pentium

Details: https://www.msi.com/Motherboard/PRO-B660M-A/support#cpu

- Socket Type: LGA 1700

- MEMORY CHANNEL: Dual
- DIMM SLOTS: 4
- MAX MEMORY (GB): 128
- PCI-E X16: 2
- PCI-E X1: 1
- SATAIII: 4
- M.2 SLOT: 2
- RAID: 0/1/5/10
- TPM (HEADER):  1
- USB 3.2 PORTS (FRONT): 1(Gen 1, Type C), 2(Gen 1, Type A)
- USB 3.2 PORTS (REAR): 2(Gen 2, Type A), 2(Gen 1, Type A)
- USB 2.0 PORTS (FRONT): 4
- USB 2.0 PORTS (REAR): 2
- SERIAL PORTS(FRONT): 1
- AUDIO PORTS (REAR): Realtek® ALC897 Codec
- DISPLAYPORT: 2
- HDMI: 2
- DIRECTX: 12
- FORM FACTOR: MATX

More details: https://www.msi.com/Motherboard/PRO-B660M-A-DDR4/Specification

MSI B660M-A Pro DDR4 Intel LGA 1700 ATX Motherboard

Compatible with Intel and AMD (check note below)

Mfr Part #: 6000J362X16RS5K UPC: 848354041481

- Memory Type: DDR5
- Pin Configuration: 288-pin
- Memory Speed: PC5-48000
- Memory Speed (MT/s): DDR5-6000
- Memory Capacity: 32GB (2 x 16GB)
- Memory Channels: Dual Memory
- Profiles: Intel XMP
- Number of Modules: 2
- Voltage: 1.35V CAS
- Latency: 36
- Memory Latency Timings: 36-36-36-96
- ECC: Non-ECC
- Buffered/Unbuffered: Unbuffered
- Memory Heatsink: Aluminum Heat Spreader
- LED Color: None
- PCB Color: Black

SN: 23404962681 SN: 23404962682

OCCT Stability Certificate: https://www.ocbase.com/stabilityCertificate/659cd4718d42416dadc20774


**Note: As best practice, please make sure to UPGRADE the BIOS of your motherboard to the latest version available which will help to minimize potential issues with new RAM modules.**

G.Skill Ripjaws S5 32GB (2x16GB) DDR5-6000 XMP 3.0

**B650M PG Riptide AMD AM5 microATX Motherboard**

BIOS updated to version 1.24

Mfr Part#: MBB650MPGRIPTID  UPC: 4710483940835

- Chipset: AMD B650
- BIOS: 256 Mb Flash ROM, UEFI AMI BIOS
- AMD CPU Support: Ryzen
- Socket Type: AM5
- Memory Type: DDR5-4800
- Memory Speeds Supported: 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5200(OC)/ 5000(OC)/ 4800
- Memory Slots: 4 x 288pin DIMM
- Memory Channel Support: Dual Channel
- Max Memory Supported: 128GB
- Maximum Memory Supported Per Slot: 32GB
- Supported Memory Technologies: ECC Memory Supported, Non-ECC Memory Supported
- Onboard Graphic Chipset: Requires CPU with Integrated Graphics
- Multi-GPU Support: 2-Way CrossFireX
- M.2 Port Type: 2260, 2280
- SATA Express: 2 x M.2 Socket 3, M Key
- SATA 6Gb/s: 4
- RAID Support: RAID 0, RAID 1, RAID 10
- Audio Chipset: Realtek ALC897
- Audio Channels: 7.1
- LAN Chipset: Dragon RTL8125BG
- LAN Speed: 10/100/1000/2500Mbps
- PCI Express 4.0 x16: 2
- PCI Express x1: 2
- LAN Ports: 1 x 10/100/1000/2500 RJ-45 LAN
- Audio Ports: 1 x 3.5 mm Microphone, 1 x 3.5 mm Line-In, 1 x 3.5 mm Line-Out
- USB 2.0: 4 x USB 2.0 (Type-A)
- Video Connectors: 1 x HDMI 2.1, 1 x DisplayPort 1.4
- USB 3.1: 1 x USB 3.2 (Gen 2 Type-C), 1 x USB 3.2 (Gen 2 Type-A), 2 x USB 3.2 (Gen 1 Type-A)
- Headers: 1 x CPU Fan Header, 1 x Water Pump Header, 3 x System Fan Header
- USB: 2 x USB 2.0 Headers (4 Ports), 2 x USB 3.2 Gen 1 Type-A Headers (4 Ports), 1 x USB 3.2 Gen 1 Type-C Header (1 Port)
- Power Connectors: 1 x 24-pin ATX Connector, 1 x 8-pin +12 V Connector, 1 x 4-pin +12 V Connector
- ATX Connector: 24-pin ATX Power Connector
- Depth: 9.60 in. (243.84 mm)
- Width: 9.60 in. (243.84 mm)
- Form Factor: microATX

ASRock B650M PG Riptide AMD AM5 microATX Motherboard

Compatible with Intel and AMD (check note below)

Mfr Part #: 6000J362X16RS5K UPC: 848354041481

- Memory Type: DDR5
- Pin Configuration: 288-pin
- Memory Speed: PC5-48000
- Memory Speed (MT/s): DDR5-6000
- Memory Capacity: 32GB (2 x 16GB)
- Memory Channels: Dual Memory
- Profiles: Intel XMP
- Number of Modules: 2
- Voltage: 1.35V CAS
- Latency: 36
- Memory Latency Timings: 36-36-36-96
- ECC: Non-ECC
- Buffered/Unbuffered: Unbuffered
- Memory Heatsink: Aluminum Heat Spreader
- LED Color: None
- PCB Color: Black

SN: 23404962202 SN: 23404962196

OCCT Stability Certificate: https://www.ocbase.com/stabilityCertificate/657f677a2b1308d639611f47

**Note: As best practice, please make sure to UPGRADE the BIOS of your motherboard to the latest version available which will help to minimize potential issues with new RAM modules.**

G.Skill Ripjaws S5 32GB (2 x 16GB) DDR5-6000 XMP 3.0

Compatible with Intel and AMD (check note below)

Mfr Part #: 6000J362X16RS5K UPC: 848354041481

- Memory Type: DDR5
- Pin Configuration: 288-pin
- Memory Speed: PC5-48000
- Memory Speed (MT/s): DDR5-6000
- Memory Capacity: 32GB (2 x 16GB)
- Memory Channels: Dual Memory
- Profiles: Intel XMP
- Number of Modules: 2
- Voltage: 1.35V CAS
- Latency: 36
- Memory Latency Timings: 36-36-36-96
- ECC: Non-ECC
- Buffered/Unbuffered: Unbuffered
- Memory Heatsink: Aluminum Heat Spreader
- LED Color: None
- PCB Color: Black

SN: 23333872557 SN: 23333872558

OCCT Stability Certificate: https://www.ocbase.com/stabilityCertificate/657df9872b1308d6394bd331

**Note: As best practice, please make sure to UPGRADE the BIOS of your motherboard to the latest version available which will help to minimize potential issues with new RAM modules.**

EVGA Z690 Classified, 121-AL-E698-KR, LGA 1700 Intel Z690 EATX Intel Motherboard

The three BIOS have been updated to the latest version available at the moment v2.12

This board supports up to 128GB of DDR5 memory, 2x 2.5Gbps NIC + Wi-Fi 6E / BT 5.2, 7.1 HD audio, and multiple USB options.

-19-Phase Digital VRM
-Twin Fans with VRM Full-Covered Heatsink
-PCIe Gen4 M.2 Key-M Slot
-PCIe Gen5 x16 Slots (x16/x8, x8)
-2x ARGB / 2x RGB Headers
-4x DDR5 DIMMs
-USB BIOS Update Port
-10-layer PCB
-Pump Headers

Items Included: Motherboard, Antennas, I/O Shield, Set of Cables.

NO OTHER PARTS OR ACCESSORIES INCLUDED

EVGA Z690 Classified 121-AL-E698-KR

Ripjaws S5 32GB (2 x 16GB) DDR5-6000 PC5-48000 CL36 Dual Channel Desktop Memory Kit F5-6000J3636F16GX2-RS5K - Black

Compatible with Intel and AMD

Mfr Part #: 6000J362X16RS5K UPC: 848354041481

Memory Type: DDR5 Pin Configuration: 288-pin Memory Speed: PC5-48000 Memory Speed (MHz): DDR5-6000 Memory Capacity: 32GB (2 x 16GB) Memory Channels: Dual Memory Profiles: Intel XMP Number of Modules: 2 Voltage: 1.35V CAS Latency: 36 Memory Latency Timings: 36-36-36-96 ECC: Non-ECC Buffered/Unbuffered: Unbuffered Memory Heatsink: Aluminum Heat Spreader PCB Color: Black

SN: 23283223309 SN: 23283223310

OCCT Stability Certificate: https://www.ocbase.com/stabilityCertificate/6561fa474956fe6a5ab961ae

**Note: As best practice, please make sure to UPGRADE the BIOS of your motherboard to the latest version available which will help to minimize potential issues with new RAM modules.**

Ripjaws S5 32GB (2 x 16GB) DDR5-6000 PC5-48000 CL36 Dual Channel Desktop Memory Kit F5-6000J3636F16GX2-RS5K - Black

Compatible with Intel and AMD

Mfr Part #: 6000J362X16RS5K UPC: 848354041481

Memory Type: DDR5 Pin Configuration: 288-pin Memory Speed: PC5-48000 Memory Speed (MHz): DDR5-6000 Memory Capacity: 32GB (2 x 16GB) Memory Channels: Dual Memory Profiles: Intel XMP Number of Modules: 2 Voltage: 1.35V CAS Latency: 36 Memory Latency Timings: 36-36-36-96 ECC: Non-ECC Buffered/Unbuffered: Unbuffered Memory Heatsink: Aluminum Heat Spreader PCB Color: Black

SN: 23293364835 SN: 23293364836

OCCT Stability Certificate: https://www.ocbase.com/stabilityCertificate/655783eb894ae03c5d1217e2

**Note: As best practice, please make sure to UPGRADE the BIOS of your motherboard to the latest version available which will help to minimize potential issues with new RAM modules.**

Ripjaws S5 32GB (2 x 16GB) DDR5-6000 PC5-48000 CL36 Dual Channel Desktop Memory Kit F5-6000J3636F16GX2-RS5K - Black

Compatible with Intel and AMD

Mfr Part #: 6000J362X16RS5K
UPC: 848354041481

Memory Type: DDR5
Pin Configuration: 288-pin
Memory Speed: PC5-48000
Memory Speed (MHz): DDR5-6000
Memory Capacity: 32GB (2 x 16GB)
Memory Channels: Dual
Memory Profiles: Intel XMP
Number of Modules: 2
Voltage: 1.35V
CAS Latency: 36
Memory Latency Timings: 36-36-36-96
ECC: Non-ECC
Buffered/Unbuffered: Unbuffered
Memory Heatsink: Aluminum Heat Spreader
PCB Color: Black

SN: 23242781968
SN: 23242781967

OCCT Stability Certificate: https://www.ocbase.com/stabilityCertificate/654b9ceec5668726014bac0d

Note:
As best practice, please make sure to UPGRADE the BIOS of your motherboard to the latest version available which will help to minimize potential issues with new RAM modules.
